MR360 Light Multifunctional Security Radar

This multi-function system is designed for applications including law enforcement, border area monitoring and control and search and rescue (SAR) support, and traffic management — any scenario requiring the search and tracking of moving targets on land, in the air, or at sea. It enables round-the-clock wide-area surveillance over land, maritime, and low-altitude air-space, facilitating timely detection of personnel, vehicles, drones, and other mobile targets, along with accurate, real-time identification of target types and trajectory data.

product details

product description

description1

description2

Product Overview

Key Features

Application Advantages:

MR360 Light Multifunctional Security Radar is primarily designed for:

Multi-Target Monitoring and Tracking: Capable of continuous wide-area search, identification, and stable tracking of various moving targets, including surface personnel, vehicles, and low-altitude slow-moving small aerial vehicles (e.g., drones).

Capable of simultaneously detecting ground personnel, vehicles, and low-altitude aerial objects.

Enables assessment of target priority levels based on behavioral patterns.

Features self-diagnostic and real-time system status display capabilities.

Impact Point Measurement and Orientation Correction:

Automatically reports target data (position points, movement trajectories, object type).

Accurately measures the impact coordinates of projected objects, providing high-precision data for exterior ballistic analysis.

★ Portable, engineered with a multi-functional, integrated architecture

★ Incorporates multi-modes, composite design.

★ Fixed-Area Situational Awareness and Coordinate Positioning

★ Ground Moving Target Monitoring and Trajectory Tracking

★ Low-Altitude Airspace Data Acquisition and Surveillance

★ Integrated for Multi-Functional Operations

Technology

This system integrates ground surveillance and low-altitude monitoring capabilities, operating in two modes: stationary stare mode and rotational scan mode. It enables simultaneous search (TWS), tracking (TAS in stare mode), and identification (TAS in stare mode) of ground and low-altitude objects including personnel, trucks, unmanned aerial vehicles, and other moving targets.

★ Planar Active Electronically Scanned Array (AESA) technology

★ 360° high-speed mechanical rotation with electronic elevation steering

★ Fully coherent pulse-Doppler processing

★ MTI + MTD + adaptive ground clutter cancellation technology

★ Linear Frequency Modulation (LFM) pulse compression

★ Composite target recognition technology combining signal and data-level features

★ RF Doppler-based simulated target generation

★ Real-time online fault detection and diagnostics

Can be rapidly deployed from a vehicle and is designed to leverage natural terrain features for low-visibility setup, enabling quick commencement of operations in field environments.
